Description
Printronix T8206e ODV-2D RFID Label Printer
The Printronix T8206e ODV-2D RFID is the ultimate industrial powerhouse, engineered for high-volume environments that demand zero errors. This 6-inch thermal printer is a “three-in-one” solution: it prints, verifies barcode quality with ODV-2D technology, and encodes RFID tags—all in a single pass.
By integrating an inline barcode verifier, the T8206e automatically scans every barcode as it’s printed. If a label fails to meet ISO standards, the printer retracts it, overstrikes the “bad” label, and automatically reprints a fresh one. This “closed-loop” system eliminates costly compliance fines and ensures 100% scannable shipments.
Key Features
-
100% Barcode Validation: The integrated ODV-2D technology finds, reads, and grades up to 50 barcodes per label (1D and 2D) to ISO standards.
-
Automatic Error Correction: If a barcode is unreadable or below grade, the printer “voids” the label and reprints it without operator intervention.
-
Single-Pass Efficiency: Simultaneously encodes RFID tags while verifying printed barcodes, drastically reducing production time.
-
Rugged Industrial Build: Features an all-metal frame and die-cast aluminum components designed for 24/7 mission-critical operations.
-
High-Speed Productivity: Capable of printing at speeds up to 12 IPS (at 203 DPI) to keep up with demanding supply chains.
-
Ease of Use: A 3.4-inch high-resolution color display with a self-help wizard and intuitive navigation keys.
-
Remote Management: Fully compatible with PrintNet Enterprise for global monitoring and configuration.
Technical Specifications
| Feature | Specification |
| Print Width | 6.6 inches (168 mm) |
| Resolution | 203 DPI (8 dots/mm) |
| Print Speed | Up to 12 IPS (304 mm/sec) |
| Memory | 512MB RAM / 128MB Flash |
| RFID Support | UHF EPC Gen2 V2 / ISO 18000-63 |
| Verification | Integrated ODV-2D (1D/2D Barcode Grading) |
| Connectivity | Standard: Ethernet, USB Device/Host, RS-232; Optional: Wi-Fi 802.11ac, Bluetooth 4.2 |
| Media Type | Roll or Fan-fold, Labels, Tags, Paper, Film |
| Construction | Die-cast Aluminum Frame with Metal Door |
Why Buy from Mindware?
-
Authorized Partner for TSC Printers
-
Sales & Service Center for TSC Barcode Printers
-
Supplier & Distributor Across India
-
1-Year Warranty
-
Free Installation & Technical Support
-
Genuine Spare Parts & Consumables
Contact Details – Price Enquiry & Support
Call / WhatsApp: 8800839490
Email: gm@indianbarcode.com
For latest price, offers, bulk orders, demo, and service support, contact Mindware today.
