ZEBRA Handheld Decoder Barcode Reader 2D Camera Barcode Scanner (Handheld)

Description

​The Zebra DS2200 Series Handheld Imagers are designed to provide affordable and reliable 1D and 2D barcode scanning solutions across various industries. This series includes both the corded DS2208 and the cordless DS2278 models, offering flexibility to meet diverse business needs.​ by from mindware.

Key Features:

• PRZM Intelligent Imaging Technology: Enhances decoding performance on poor-quality barcodes, ensuring first-time, every-time scanning.​

• Omni-Directional Scanning: Allows users to scan barcodes from any angle without the need for precise alignment, improving efficiency.​

• Intuitive Aiming Line: Provides a familiar aiming pattern similar to 1D scanners, guiding users to the optimal scanning distance.​

• Flexible Charging Options: The DS2278 can be charged via a Micro USB cable or a Presentation Cradle, accommodating various operational setups.​

• Wi-Fi Friendly Mode: Prevents Bluetooth interference by ensuring the cordless DS2278 operates on channels not shared with your Wi-Fi network.​

Physical Characteristics:

• Dimensions:

  • DS2208 (Corded): 6.5 in. H x 2.6 in. W x 3.9 in. D (16.5 cm H x 6.6 cm W x 9.9 cm D)​

  • DS2278 (Cordless): 6.9 in. H x 2.6 in. W x 3.5 in. D (17.5 cm H x 6.6 cm W x 9.0 cm D)​

  • Presentation Cradle: 2.8 in. H x 3.7 in. W x 4.8 in. D (7.2 cm H x 9.4 cm W x 12.2 cm D)​

• Weight:

  • DS2208: 5.7 oz. (161.6 g)​

  • DS2278: 7.5 oz. (214 g)​

  • Presentation Cradle: 5.2 oz. (151 g)​

Performance Characteristics:

• Motion Tolerance (Handheld): Up to 5 in./13 cm per second for 13 mil UPC​

• Swipe Speed (Hands-Free): Up to 30 in./76.2 cm per second for 13 mil UPC​

• Image Sensor: 640 x 480 pixels​

• Field of View: 32.8° H x 24.8° V nominal​

• Minimum Print Contrast: 25% minimum reflective difference​

User Environment:

• Operating Temperature: 32°F to 122°F (0°C to 50°C)​

• Storage Temperature: -40°F to 158°F (-40°C to 70°C)​

• Humidity: 5% to 95% RH, non-condensing​

• Drop Specification: Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete​

• Environmental Sealing: IP52​

• Battery Capacity: 2,400 mAh Li-Ion Battery​

• Scans Per Charge: Up to 110,000 scans at 60 scans per minute​

• Operating Time Per Full Charge: Approximately 84 hours​

The DS2200 Series is suitable for various applications, including retail point-of-sale, hospitality check-in, and light manufacturing product tracking. Its ease of deployment, user-friendly features, and manageability make it a valuable tool for businesses seeking efficient barcode scanning solution.
